In 2018 and 2019, low-temperature triaxial compressive strength simulation experiments were conducted on frozen soil in Qingdao, Shandong Province. The observed factors included sample density, ambient temperature, confining pressure, compressive strength, peak strength, etc. The time range for data resource collection was from April 20, 2018 to April 20, 2019. A low-temperature triaxial experimental device was used to measure the triaxial compressive strength of Mohe permafrost and Dongying permafrost at different burial depths, temperatures, and confining pressures. Used to study the variation of mechanical parameters of frozen soil layer with temperature and confining pressure, and establish a prediction model for geotechnical engineering mechanical parameters of frozen soil layer.
Experimental experiments, independently generated.
The data collection uses the servo controlled low-temperature conventional three-axis experimental system of China University of Petroleum. Technical parameters: 1. Maximum axial force: 1000kN; 2. Test force accuracy: ± 1%; 3. Test force resolution: 1/120000; 4. Maximum piston displacement: 100mm; 5. Displacement accuracy: ± 1%; 6. Displacement resolution: 1/100000; 7. Axial deformation measurement range: 0-8mm; 8. Radial deformation measurement range: 0-4mm; 9. Deformation measurement accuracy: ± 1%; 10. Deformation resolution: 1/100000; 11. Maximum confining pressure: 100MPa; 12. confining pressure accuracy: ± 2%; 13. Resolution of confining pressure: 1/60000.
Good data quality
| # | number | name | type |
| 1 | 2016YFC0303300 | National key R & D plan |
This work is licensed under a
Creative
Commons Attribution 4.0 International License.
CSTR:11738.11.ncdc.SRIPE.db1705.2022
10.12072/ncdc.SRIPE.db1705.2022
