Three drilling rig design calculation reports obtained using finite element analysis method in Jingzhou, Hubei from 2017 to 2020. The calculation content includes the strength and stability calculation of the drilling rig structure, the calculation of the main parameters of the winch and the strength of the main drum, the thermal balance calculation of the insulation area, lower area, solid control and auxiliary area of the drilling rig. The calculation results show that the drilling rig design scheme meets the requirements of -50 ℃ ambient temperature and 12000m well depth. In addition, this dataset includes speed, rated speed, power, frequency, hook speed, hook load, outdoor wind speed, outdoor temperature, length, area, weight, corrected weight, specifications, lateral load, etc.
This dataset was obtained through finite element analysis software calculations. The data collection location is Sinopec Siji Petroleum Machinery Co., Ltd. in Jingzhou, Hubei Province, and the software used for the collection is SAFI PSE V12.0.2 、Fluent V19.2、Solidworks simulation V2013。
Analyze using software such as SAFI PSE V12.0.2, Fluent V19.2, Solidworks simulation V2013, etc. Calculation and evaluation reference standards include API 4F, ANSI/AISC 360, GB/T23505, etc.
The data quality is good.
| # | number | name | type |
| 1 | 2016YFC0303300 | National key R & D plan |
