Atlas of Drilling Tool Plans (2018-2020)
  • 2022/02/25 19:49
  • 2043
  • 1
English name
Atlas of Drilling Tool Plans (2018-2020)
CSTR
CSTR:11738.11.ncdc.SRIPE.db1684.2022
DOI
10.12072/ncdc.SRIPE.db1684.2022
Share type
Online
Category
Others
source site
Study on key drilling technology in polar cold sea
contributors
chi shenggao
Datasets description

    Five general drawings of drilling tools designed using CAD software in Wuhan, Hubei from 2017 to 2020, including PDC drill bits, coring drill bits, impregnated drill bits, screw drilling tools, and turbine drilling tools. The time coverage of resources is from January 1, 2018 to December 30, 2020. The geographical coverage of resources is Wuhan City, Hubei Province. A 3D model is drawn using the 3D drawing software UG to generate a 2D engineering drawing, which includes the overall structure, appearance, and overall dimensions of the drill bit and drilling tool.

Base information
collect time 2018/01/01  -  2020/12/31
collect place Wuhan City, Hubei Province
data size 2.5 MiB
data format pdf
Coordinate system
Data thumbnail
Data source description

    Experimental experiments, independently generated.

Data processing method

    Use the 3D drawing software UG to create a 3D model and generate a 2D engineering drawing, which includes the overall structure, appearance, and dimensions of the drill bit and drilling tool.

Data quality description

    The data quality is good.

Project information
# number name type
1 2016YFC0303300 National key R & D plan
Citations and annotations
In order to protect the rights and interests of the platform's scientific and technological resources, expand the services of the platform center, and enhance the application potential of scientific and technological resources, resource users are requested to mark and quote the research results (including published papers, treatises, data products, unpublished research reports, data products, etc.) generated by the use of resources in the following manner.

For the achievements published in English, please refer to the following specifications： The dataset is provided by National Cryosphere Desert Data Center. (http://www.ncdc.ac.cn).

Data reference
  1. chi shenggao. Atlas of Drilling Tool Plans (2018-2020). National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2022. https://cstr.cn/CSTR:11738.11.ncdc.SRIPE.db1684.2022.
  2. chi shenggao. Atlas of Drilling Tool Plans (2018-2020). National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2022. https://www.doi.org/10.12072/ncdc.SRIPE.db1684.2022.
license agreement
Creative Commons License   This work is licensed under a Creative Commons Attribution 4.0 International License.
